IBM SurePOS 700 Series Hardware Service Guide

Removing the top cover
To remove the top cover:
1. Locate the metal holding clip located in the rear center of the top cover (C in
Figure 21).
2. Push this clip downward and push the cover backward a few inches, then lift
upward to remove.
C
Figure 21. Removing the top cover
34 SurePOS 700-723/743/783/784 Hardware Service Guide
