IBM SurePOS 700 Series Hardware Service Guide

Removing the covers
The procedures in this section apply to all models and to both the wide and narrow
features. The covers consists of the following parts:
v Front bezel
v Hinged rear door (modesty cover)
v Top cover
Removing the front bezel
To remove the front bezel:
1. Press the right latch (C) and depress the center latch that hooks into the
center tab (A) to loosen the bezel.
A
C
Figure 19. Removing the front bezel
Chapter 2. Removal and replacement procedures 31
