IBM SurePOS 700 Series Hardware Service Guide

Replacing the top cover
To replace the top cover:
1. Place the top cover in position over the system unit so that the front edge aligns
with the line imprinted on the top plate (A in Figure 22).
2. Press the top cover sides down and inward slightly while sliding the cover
forward, to lock it into place. Pull cover as far forward as it will go.
3. Close the rear door by pressing downward on the door.
A
Figure 22. Installing the top cover
Chapter 2. Removal and replacement procedures 35
