IBM System x3200 Installation Guide

Removing the side cover
To remove the server side cover, complete the following steps:
1. Review the safety information that begins on page v and the “Installation
guidelines” on page 7.
2. Turn off the server and all attached devices (see “Turning off the server” on
page 41); then, disconnect all power cords and external cables.
3. Lay the server on its side.
4. Unlock the side cover; then, press the cover-release latch down, as indicated by
the two arrows on the latch.
Cover-release
latch
Key lock
5. Lift the side cover off the server and set it aside.
To
replace the side cover, see “Reinstalling the side cover” on page 34.
Attention: For proper cooling and airflow, replace the cover before you turn on
the server. Operating the server for extended periods of time (more than 30
minutes) with the cover removed might damage server components.
10 System x3200 Type 4362 and 4363: Installation Guide

IBM System x3200 Specifications

General

Form Factor	Tower
Network	Integrated Gigabit Ethernet
Processor	Intel Xeon 3000 sequence, Intel Pentium Dual-Core processor, Intel Celeron processor
Processor Cores	Dual-Core
Chipset	Intel 3000
Memory	Up to 8GB DDR2
Memory Slots	4
Storage	SATA HDD
RAID Support	RAID 0, 1
Drive Bays	4 internal 3.5-inch
