Reinstalling the side cover
If you removed the bezel, reinstall it before you reinstall the side cover. See
“Reinstalling the two-piece bezel” on page 32.
Note: The rear adapter-retention bracket rests against the server side cover. You
might find it easier to lay the server on its side to reinstall the side cover.
Cover-release
latch
Key lock
To reinstall the side cover, complete the following steps:
1. Before you install the side cover, make sure that all cables, adapters, and other
components are installed and seated correctly and that you have not left loose
tools or parts inside the server. Also, make sure that all internal cables are
correctly routed.
Note: The cover-release latch must be in the unlocked (opened) position before
you install the side cover.
2. Insert the tabs inside the cover into the slots on the server chassis.
Note: Make sure that each tab on the side cover is in its corresponding slot
before you close the cover-release latch.
3. Close the cover-release latch to secure the side cover in place.
4. Lock the side cover.
34 System x3200 Type 4362 and 4363: Installation Guide
