IBM System x3650 M4 Type 7915 - Page 108

0
1
2
3
Configuration cable
(Connector for drive
bays 0-7 and 8-15)
Configuration cable
(Connector for drive
bays 16-23)
SAS/SATA backplane
config connector 1
SAS/SATA backplane
config connector 2
Note: Leave the cable segment with the label 3 unconnected.
15. Make sure that the SAS power cable is connected to the backplanes and
system board.
90 System x3650 M4 Type 7915: Installation and User’s Guide
