Battery
Battery cable
connector
Note: The positioning of the remote battery depends on the type of remote
battery that you install.
b. Connect the other end of the battery cable to the battery cable connector on
the battery.
c. Place the battery retention clip underneath while pressing the release tab
toward the front of the server until it snaps in place to hold the battery
retention clip firmly in place.
Note: The battery must recharge for at least 6 hours under normal operating
conditions. To protect your data, the ServeRAID controller firmware changes the
write policy to write-through until the battery unit is sufficiently charged. When the
battery unit is charged, the ServeRAID controller firmware changes the write policy
to write-back.
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 135.
Installing a USB hypervisor memory key
Hypervisor is a virtualization platform that enables multiple operating systems to run
on a host computer at the same time. Support for hypervisor is available with the
purchase and installation of an optional USB hypervisor memory key, with
embedded hypervisor software.
To install the USB hypervisor memory key, complete the following steps:
1. Read the safety information that begins on page vii and “Installation guidelines”
on page 40.
128 System x3650 M4 Type 7915: Installation and User’s Guide

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
