IBM System x3650 M4 Type 7915 User Manual

Removing a USB hypervisor memory key
To remove the USB hypervisor memory key, complete the following steps:
1. Read the safety information that begins on page vii and “Installation guidelines”
on page 40.
2. Turn off the server and peripheral devices and disconnect all power cords and
external cables (see “Turning off the server” on page 28).
3. Remove the cover (see “Removing the cover” on page 54).
4. Remove the flash device:
USB embedded
hypervisor
flash device
Lockbar
a. Unlock the retention latch on the USB connector by squeezing the two
retention clips toward each other.
b. Open the retention latch.
c. Grasp the flash device and pull to remove it from the connector.
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 135.
Note: You must configure the server not to look for the hypervisor USB drive. See
Chapter 3, “Configuring the server,” on page 141 for information about disabling
hypervisor support.
130 System x3650 M4 Type 7915: Installation and User’s Guide
