IBM System x3650 M4 Type 7915 - Installing a Hot-Swap AC Power Supply

2
3
Configuration cable
(Connector for drive
bays 16-31)
SAS/SATA backplane
config connector 2
15. Make sure that the SAS power cable is connected to the backplanes and
system board.
Chapter 2. Installing optional devices 97
