Table 2. System-board jumper blocks (continued)
Jumper number Jumper name Jumper setting
J31 Trusted Platform Module
(TPM) jumper
Pins 1 and 2: Enable TPM
physical presence.To enable
TPM physical presence,
complete the following steps:
1. Turn off the server and
remove all power cords
and external cables.
2. Remove the pin jumper
from JP6 and install it on
J31 pins 1 and 2. Take
note which pins the
jumper is originally
installed on JP6.
3. Turn on the server and
access the Setup utility
menu to verify that the
TPM function has been
activated (see “Using the
Setup utility” on page
225).
4. Turn off the server and
replace the jumper on
JP6.
5. Turn on the server.
Notes:
v If no jumper is present in JP1 or JP6, the server responds as if the pins are set to 1 and
2.
v Changing the position of the boot block jumper from pins 1 and 2 to pins 2 and 3 before
the server is turned on alters which flash ROM page is loaded. Do not change the jumper
pin position after the server is turned on. This can cause an unpredictable problem.
