Microprocessor
Handle
Installation
tool
10. Carefully position the microprocessor with the microprocessor tool over the
microprocessor socket. Twist the microprocessor tool counterclockwise to
insert the microprocessor into the socket.
11. Close the load plate and then rotate the microprocessor-release lever to
secure the microprocessor.
58 IBM System x3850 X5 and x3950 X5 Types 7145 and 7146: Installation and User’s Guide
