Torus 126, 380 and 500 Operator Manual
4-6 Printer LED Functions
Rev AB
Printer LED Functions
The printer has a dual colored LED below the CLARiTY™ interface that
indicates the status of the printer (Figure 4-5).
The LED states and their functions are shown in Table 4-2.
Add Ink
This section describes the following topics:
• How to review the status of the ink
• Correct time to insert a new ink canister
• The number of prints possible with the available ink
Review the Ink Status
The Consumables area of the Home Page screen displays a percentage
value of ink that is left in the ink canister of the printer. For example refer
to Figure 4-6 on page 4-7.
LED States Function
Green (constant) On-line, ready to print
Green (flashing) On-line and printing (LED flashes
for every print)
Orange (Flashing) CLARiTY update in progress
Red (constant) Off-line
Red (flashing) Fault condition
Table 4-2: LED Status and their Functions
