Ice Torus 126 User Manual

Torus 126, 380 and 500 Operator Manual
Rev AB Print Position Adjustment 5-11
Print Position Adjustment
To adjust the position of the print with reference to the front edge of the
box, do the following tasks:
1 Navigate to Tools > Setup > Printhead in the Home Page. The Printhead
setup page appears (
Figure 5-14).
2 Touch the Registration Delay icon. Enter the new print position (in
millimeters) with the keypad (
Figure 5-15).
Follow any of the below methods to make the adjustments:
•Touch the and icons to make small adjustments in the
position.
• Touch the data entry pad icon and use the pad to enter a new number
(
Figure 5-16 on page 5-12).
• Enter the Min, Max or Default values (Figure 5-17 on page 5-13).
Figure 5-14: Printhead Setup Screen
Tools
