Torus 126, 380 and 500 Operator Manual
Rev AB Set the Air Pressure 4-3
Set the Air Pressure
The printer comes with an air regulator. During the installation of the
printer, the air regulator must be installed near the printer.
To increase the pressure, turn the air regulator control knob to the right
side. To decrease the pressure, turn the knob to the left side (Figure 4-3 on
page 4-4).
The air pressure must be set according to the printer type. Follow the
recommended values. The failure to follow this caution can decrease
the efficiency of the printer.
The air pressure requirement for the Torus 126/380/500 is shown in the
Table 4-1.
Printer Type Air Pressure
Torus 126 2.5 Bar
Torus 380 3.5 Bar
Torus 500 4.5 Bar
Table 4-1: Air Pressures
