Torus 126, 380 and 500 Operator Manual
4-18 Clean the Printhead
Rev AB
Figure 4-19: Printhead Jetting Face
1. Printhead Nozzle Plate
2. Blow Nozzle Plate
3. Ink Collector
4. Knife Edge
5. Ink Drain Channel
6. Printhead Front Plate
1
2
3
4
5
6
