ICM Controls i3 2010WR User Manual

18
WARNING! : Incorrectsettingscandamagesystemand/orcausepotentiallydangerous
conditions.UsethecodedescribedinCongurationSafetyLocktoaccessthisscreensetting.
19.TemperatureSensor(L,r,A,rsleep)
Note:If there is no remote sensor, option 1 (L) must be selected. May only be used with remote
temperature sensor 1.
CONFIG
Appearsonlyfornon-heatpumpsystemsandheatpumpswithoutanoutdoorsensor.
1.L–Onlyon-boardsensordeterminesroomtemperature.
2.r–Onlyremotesensordeterminesroomtemperature.
3.A–Averagetemperatureofon-boardandremotesensor.
4.rSleep–Onlyon-boardsensorwillbeuseduntilSLEEPperiod,andthenonlyremotesensorisusedforSLEEPperiod.
Pressthe
or toselect.Press toadvancetothenextscreen.
20.FanDelayOffTime(0,30,60,90seconds)
Selecttheamountoftimethefancontinuestooperateafterthecool/heatdemandhasbeen
satised.Functionsforcooling,heatpumpsandelectricheat.
Press
or toselect.
Press
toadvancetothenextscreen.
CONFIG
21.HourlyCycleFanOperation(1-30 minutes per hour)
UsedinconjunctionwiththeFanHOURLYmode.Whentheuserselectsthisoption,thefanwill
turnonatthebeginningofeveryhourandrunforthenumberofminutesindicatedhere.
Press
or toselect.
Press
toadvancetothenextscreen.
CONFIG
HOURLY
22.FanonSchedule(OFF,WAKE,LEAVE,RETURN,SLEEP)
ThefanwillruncontinuouslyduringthisscheduledperiodwhenthemodeisnotsettoOFF.To
turnonthefanduringoneofthescheduledperiods(WAKE,LEAVE,RETURN,SLEEP),please
dothefollowing:
Press
or toselect.
Press
toadvancetothenextscreen.
CONFIG
ON
SCHEDULEFAN
OFF
