Icom IC-M88 - Function Display Indicators

■ Function display
qw ertyu
i
o
!0
!1
!2
!3!4
!5
!6
!7
q TRANSMIT INDICATOR(p.10)
 Appearswhiletransmitting.
w BUSY INDICATOR(p.10)
 Appears when receivinga signal or when the squelch
opens.
“
” blinks while monitoring.
e TAG CHANNEL INDICATOR (p.14)
 Appearswhenatagchannelisselected.
r SCAN INDICATOR (p.14)
 Blinkswhilescanning.
t LOCK INDICATOR(p.12)
 Appearswhilethelockfunctionisactivated.
y NARROW INDICATOR(p.16)
 Appearswhennarrowchannelspacingisselected.(LAND
channelgrouponly)
u BATTERY INDICATOR
Indicates remaining battery power.
Indication
Full Middle
Charging
required
Discharged
Battery level
blinks when the battery is over charged.
6
3
PANELDESCRIPTION
