Icom IC-R2500 - Rear Panel-Main Unit

9
2
PANEL DESCRIPTION
■ Rear panel—main unit
Front
Top
Rear
Power switch
Speaker
DATA
PACKET 1
USB EXT SP
ANT 1 ANT 2
DC IN
GND
PACKET 2
qwe r q
t
i
uy
2-conductor 3.5 (d) mm (
1
⁄8˝)/100 kΩ
PACKET jack connection
2-conductor 3.5 (d) mm (
1
⁄8˝)/8 Ω
EXT SP jack connection
AUDIO
GND
AUDIO
GND
Left band Right band
