Icom IC-T2H Instruction Manual

40
16
MODE ARRANGEMENT
CHANNEL INDICATION MODE
VFO MODE
MEMORY MODE
CALL MODE
DTMF MEMORY MODE
+
AT POWER ON
See p. 11 for details
SET MODE
MR
0
VIA CLONING
See p. 33 for details
See p. 22 for details
Refer to the CS-T2
cloning software
read me file for details.
ANI MODE
[ (DTMF)]
[
A V]/[ (CALL)]
for 1 sec.
T
Repeater tone (p. 16)
T SQL
CTCSS tone (p. 26)
Tone setting
DUP
Frequency offset (p. 16)
Duplex setting (p. 15)
Tuning step (p. 14)
CALL frequency (p. 20)
NOTE: indicates one of the
customizable keys (see page
at right).
[A V]/[ (CALL)]
momentarily
[ (DTMF)]
[A V]
[
A V]
[ (CALL)]
[ (CALL)]
(Transmit DTMF
code.)
IC-T2H Manual 01.12.5 4:31 PM Page 40 (1,1)

Icom IC-T2H Specifications

General

Frequency Range	144-146 MHz
Modulation	FM
Power Output	5W
Weight	320g
RF Power Output	5W
Voltage	9.6 VDC
