Icom ID-1

98
13
POCKET BEEP AND TONE/DIGITAL SQUELCH
New2001
13
DD
Setting from the RC-24
qSet the desired operating frequency and mode (FM or Dig-
ital voice).
• Using the CTCSS— in FM mode
wPush [TXinh• ] for 0.5 sec. to enter set mode.
ePush [MODE] or [TXinh• ] several times to select
“CTCSS Tone” item.
rRotate [DIAL] to select the desired tone squelch frequency.
• After the selection, push [PWR] momentarily to exit set mode.
tPush [TONE••5] once or twice to turn the tone squelch
function ON.
•“TSQL” appear.
yWhen a signal with matched tone is received, the squelch
opens and emits received signal.
• When the received signal includes an unmatched tone, the
squelch does not open. However, the S/RF indicator shows the
received signal strength.
uPush [PTT] to answer.
iPush [TONE••5] once to cancel the tone squelch func-
tion.
•“TSQL” disappears.
• Using the digital code squelch— in Digital voice mode
wPush [TXinh• ] for 0.5 sec. to enter set mode.
ePush [MODE] or [TXinh• ] several times to select
“Digital Code” item.
rRotate [DIAL] to select the desired code number.
• After the selection, push [PWR] momentarily to exit set mode.
tPush [TONE••5] several times “CSQL” appears to turn
the digital code squelch function ON.
yWhen a signal with matched digital code is received, the
squelch opens and emits received signal.
• When the received signal includes an unmatched code, the
squelch does not open. However, the S/RF indicator shows the
received signal strength.
uPush [PTT] to answer.
• When the called station call sign is not selected in “UR,” push
[CS••1] for 0.5 sec. to display receive call sign indication
mode then push [SQL] for 0.5 sec. to set the call sign before
pushing [PTT].
Digital Code
00
CTCSS Tone
88.5
[MODE]
[TXinh• ]
