70
9
DATA OPERATION
New2001
9
■ Low-speed data communication
In addition to the data communication, a low-speed data com-
munication capability is available.
Low-speed data communications require narrow passband
width, thus digital voice mode is used and provides a simul-
taneous operation with voice and data.
qSet the desired frequency.
wSelect DV (Digital voice) mode.
• Click [MODE] on the main screen or push [MODE] on the RC-
24.
eSet another settings, such as repeater, digital code
squelch, transmit output power.
rClick “” or select “Exit(X
)” in File menu to quit the appli-
cation.
NOTE: The application must be quit during low-speed data
operation. The application and a low-speed data commu-
nication software cannot be operated simultaneously, due
to both of data passing through the ID-1 USB port.
tStart up the low-speed data communication application.
ySet the application as follows.
• Port : The same COM port number as ID-1’s
• Baud rate : 19200 bps
• Data : 8 bit
• Parity : None
• Stop : 1 bit
• Flow control : Xon/Xoff
uPush and hold [PTT] to transmit, release to receive the
data.
• Refer to the instruction of the application that how to send or re-
ceive data.
NOTE:
• A communication error may occur depending on the com-
bination of the OS used, and the low-speed data commu-
nication application installed in your PC.
•“Packet-loss” (loosing a part of data) may occur when
communicating through internet network. When “Packet-
loss” occurs, [TX/RX] indicator lights orange.
• ASCII code’s characters are only usable.
ID-1_ENG_2.qxd 04.9.22 9:29 Page 70 (1,1)
