Icom ID-800H

122
14
SPECIFICATIONS AND OPTIONS
14
■ Options
HM-133 REMOTE - CONTROL MICROPHONE
Wired remote control microphone with key backlight. Same as that
supplied with the transceiver.
HM-118N HAND MICROPHONE
For all-round mobile operation.
OPC-600/600R*, OPC-601/601R* SEPARATION CABLES
OPC-600/600R: Same as that supplied with the transceiver. 3.5 m
(11.5 ft)
OPC-601/601R: For extended separate installation. 7.0 m (23.0 ft)
* A ferrite core is supplied with the OPC-600R or OPC-601R for the
USA version.
MB-58 REMOTE CONTROLLER BRACKET
Mounts the remote controller in a convenient location for operation
with the front panel detached from the main body.
MB-65 MOUNTING BASE
Mounts the remote controller on to variety of place in vehicle. MB-84
is required for mounting.
MB-17A MOBILE MOUNTING BRACKET
One-touch bracket. Transceiver main unit easily attached or re-
moved.
OPC-440/OPC-647 MIC EXTENSION CABLES
OPC-440: 5.0 m (16.4 ft); OPC-647: 2.5 m (8.2 ft)
OPC-441 SPEAKER EXTENSION CABLE
5.0 m (16.4 ft)
SP-7/SP-10 EXTERNAL SPEAKERS
SP-7: For base station use. Cable length: 1.0 m; 3.3 ft
SP-10: For all-round mobile operation. Cable length: 1.5 m; 4.9 ft
OPC-347/OPC-1132 DC POWER CABLES
OPC-347: 7.0 m (23 ft)
OPC-1132: 3.0 m (9.8 ft) Same as that supplied with the transceiver.
CS-D800 CLONING SOFTWARE + OPC-478U CLONING CABLE
Provides quick and easy programming items, such as memory chan-
nels, set mode contents for local repeater frequencies, via PC’s USB
terminal. RS-232 type cloning cable, OPC-478, also available.
OPC-474 CLONING CABLE
Used for data cloning between transceivers.
OPC-1384 DATA COMMUNICATION CABLE
Used for data communication between transceiver and PC (or GPS
receiver). (Mini DIN 8 pin ⇔ RS-232 D-sub 9 pin)
ID-800H_1.qxd 2007.06.14 3:09 PM Page 122
