Icom ID-800H

IX
QUICK REFERENCE GUIDE
■ Repeater operation
1. Setting duplex
➥ Push [BAND•MODE] and rotate [DIAL], then push
[BAND•MODE] to select the desired frequency band.
➥ Push and hold [LOW•DUP] for 1 sec. once or twice to se-
lect minus duplex or plus duplex.
• The USA version has an auto repeater function, therefore, set-
ting duplex is not required.
2. Repeater tone
Push [TONE•T-SCAN] several times until “T” appears, if the
repeater requires a subaudible tone to be accessed.
Using the HM-133
Plus or minus duplex selection and the repeater tone setting
can be made easily via HM-133.
Push and hold [
DUP – 7(TONE)] for minus duplex;
[
DUP + 8(TSQL
SS
)] for plus duplex selection, push [FUNC]
then [
DUP – 7(TONE)] to turn the repeater tone ON.
Push
Push , then
Push
[TONE•T-SCAN]
[LOW•DUP]
