Icom ID-800H

VII
QUICK REFERENCE GUIDE
■ Your first contact
Now that you have your ID-800H installed in your car or
shack, you are probably excited to get on the air. We would
like to take you through a few basic operation steps to make
your first “On The Air” an enjoyable experience.
1. Turning ON the transceiver
Before powering up your ID-800H, you may want to make
sure the audio volume and squelch level controls are set in
9–10 o’clock positions.
Although you have purchased a brand new transceiver, some
settings may be changed from the factory defaults because
of the quality control process. Resetting the CPU is neces-
sary to start from factory default.
➥ While pushing both [SET•LOCK] and [S.MW•MW], push
and hold [PWR] for 1 sec. to reset the CPU.
2. Selecting the operating frequency band
The ID-800H has 2 m and 70 cm transmittable bands.
➥ Push [BAND•MODE] momentarily to enter band selection
mode.
➥ Rotate [DIAL] to select the desired frequency band, then
push [BAND•MODE] to set the selected band.
[DIAL]
[BAND•MODE]
[PWR]
[SET•LOCK]
[S.MW•MW]
[VOL]
[SQL]
