Key No. Description Qty. Product No.
1 Burner bar (Bray) 1 058 014
2 Ignition electrode 1 100 613
3 Sensing electrode 1 100 612
4 Burner cork gasket (round) 1 012 589
5 Burner bre glass gasket 1 057 860
6 Fan assembly 1 100 321
7 Sight glass frame, glass and gasket 1 078 881
8 Burner injector and gasket 1 079 722
9 Gas valve with gas/air control unit assembly 1 079 723
10 Negative pressure sensing line assembly 1 079 724
11 Positive pressure sensing line assembly 1 079 725
12 Safety temperature limiter manual reset LM5 1 004 038
13 Adjustable control knob - Bulgin 1 013 241
14 Adjustable control thermostat sensor 1 058 512
15 Adjustable control thermostat potentiometer assembly 1 100 614
16 Reset switch assembly (Lockout) 1 004 346
17 Printed circuit board PCB No. 28 1 100 646
18 Printed circuit board PCB No. 29 1 100 647
19 Module cover assembly - Vertical 1 100 823
20 Module cover lter 1 100 619
21 Printed circuit board PCB No.. 30 1 100 648
22 Module ange gaskets 2 012 745
23 Module top cover plate gasket 1 100 936
24 Module bottom cover plate gasket 1 100 935
25 Module cover assembly - Horizontal 1 100 824
26 Header gaskets (triangular) 2 012 593
27 Gas distribution screen (aluminium wrapper) 1 100 804
28 Fan outlet cork gasket (square) 2 057 860
29 Fan scroll gasket (round) 1 --
The following list compromises parts commonly required as
replacement components due to damage, expendability, or
such that their failure or absence is likely to affect safety or
performance.
The list is extracted from the British Gas List of Parts, which
contains all available spare parts.
Details of the British Gas Lists are held by gas regions, Ideal
Boilers distributors and by merchants.
Ideal Concord Super Series 4, 500-600 Vert., 350-600 Hor.
When ordering spares please quote:
1. Boiler Model
2. Appliance G.C. Number
3. Product Code
4. Quantity
SERVICING AND FAULT FINDING
