IDEAL Concord Super Series 4 50 V User Manual

5
Concord Super Series 4 - Installation & Servicing
TECHNICAL DATA
Table 2
Boiler 350 V 400 V 450 V 500 V 550 V 600 V 450 H 500 H 550 H 600 H
No. of modules 7 8 9 10 11 12 9 10 11 12
Heat output kW 350 400 450 500 550 600 450 500 550 600
Btu/h x 10
3
1194 1365 1535 1706 1877 2047 1535 1706 1877 2047
Heat input kW 411.6 470.4 592.2 588.0 646.8 705.6 529.2 588.0 646.8 705.6
Btu/h x 10
3
1404 1605 1806 2006 2207 2407 1806 2006 2207 2407
Gas rate m
3
/h 38.6 44.1 49.7 55.2 60.7 66.2 49.7 55.2 60.7 66.2
ft.
3
/h 1363 1557 1752 1947 2143 2336 1752 1947 2143 2336
Flue gas mass
volume *
at 120ºC (248ºF)
g/s 175 200 225 250 275 300 225 250 275 300
l/s 191 219 246 273 301 328 246 273 301 328
ft.
3
/min 406 464 522 580 638 696 522 580 638 696
Required water
ow rate ± 10%
l/s 7.49 8.56 9.63 10.70 11.77 12.84 9.63 10.70 11.77 12.84
gal./min. 98.7 112.8 126.9 141.0 155.1 169.2 126.9 141.0 155.1 169.2
Hydraulic resistance 12.5 kN/m
2
(50 in w.g.)
Maximum static head** 2 m (6.5 ft.)
Maximum static head 60.0 m (197 ft.) 6.0 bar (85 lb/in
2
)
Electricity supply 230 V ~ 50Hz,
Power consumption W 630 720 810 900 990 1080 810 900 990 1080
Gas supply pressure
20.0 mbar (8 in. w.g.)
Boiler height
(overall)
mm 1618 1618 2144 2144 2144 2144 1467 1467 1467 1467
in. 63.7 63.7 84.4 84.4 84.4 84.4 57.8 57.8 57.8 57.8
Boiler width
(overall)
m m 1822 1822 1833 1833 1833 1833 2393 2393 2393 2393
in. 71.7 71.7 72.2 72.2 72.2 72.2 94.2 94.2 94.2 94.2
Boiler depth (overall) 1350 mm (53.1 in.)
Weight of casing
and insulation
kg. 134 126 197 190 182 175 197 190 182 175
lb. 295 278 435 418 402 386 435 418 402 386
Weight of
modules
kg. 371 424 477 530 583 636 477 530 583 636
lb. 818 935 1052 1168 1282 1402 1052 1168 1282 1402
Weight of gas &
water headers
kg. 260 263 311 313 315 318 298 300 302 304
lb. 573 580 686 690 694 701 657 661 665 670
Water content
boiler
l. 63.3 68.1 97.6 102.4 107.2 112 92.6 97.4 102.2 107
gal. 14.1 15.1 21.6 22.7 23.9 24.9 20.5 21.6 22.7 23.7
Flow and return
connection
mm 100 100 125 125 125 125 125 125 125 125
in. 4.0 4.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
Gas connection Rc 2 2 2 2 2 2 2 2 2 2
in. BSP 2 2 2 2 2 2 2 2 2 2
Flue pipe size
(nominal bore)
mm 350 350 400 400 450 450 400 400 450 450
in. 14 14 16 16 18 18 16 16 18 18
Flue socket size mm 400 400 450 450 501 501 450 450 501 501
in. 15
3
/4 15
3
/4 17
1
/4 17
1
/4 19
3
/4 19
3
/4 17
3
/4 17
3
/4 19
3
/4 19
3
/4
Injector size 7.3 mm (0.28 in.)
Type of gas Natural gas (G20 only)
GENERAL
