12
S1
PRESSURISATION UNIT
BOILER PUMP
HEATING PUMP
TO HEATING CIRCUITS
PRIMARY HWS 1
HWS SENSOR
FROM HEATING CIRCUITS
P1
P2
P3
S2
TO DRAIN
S3
TANK
SECONDARY
HWS 1
P5
LOW
LOSS
MIXING
HEADER
SYSTEM LAYOUT
TYPICAL SYSTEM BOILER LAYOUT
* Low loss header may not be required depending on system design and pump sizing
