21
EVOMAX CASCADE
LOW HEIGHT FRAME & HEADER KITS
BOILER FRAME AND HEADER KITS
The Low Height Frame and Header Kits make installation much simpler in circumstances of reduced headroom,
offering an option of replacing a floor standing atmospheric boiler with a high efficiency model.
Three options are available allowing for outputs from 30 kW to 450 kW.
• Frame and Header Kits fit easily through
standard doorways
• Lift weights are as low as possible
• The Low Height Frame and Header Kit is supplied on one
palette shrink wrapped together with all ancillary fittings
needed for assembly
• All pipe work connections are supplied with either the
boiler, header kit or are pre assembled to the header kit
• Pre assembled to header; the boiler the flow and return
flexible connections, which reduce installation time
• Delivered with header kit; connection pipe assembly, non
return valves & pipe work connector, all isolation valves,
pressure relief valve, drain cock and associated fittings
• The Low Height Frame and Header Kit can be installed
with either an Ideal Commercial Sequencer offering direct
modulation of the system, reducing running costs, or a
proprietary option
• The extremely compact dimensions allow for replacement
of existing standard efficiency floor standing boilers,
using a single wall mounted condensing boiler up to 150
kW allowing sufficient space to install flue system, pump
and pipe headers
• High quality and well-finished components
• Supplied with frames and low energy modulating pumps
(ErP approved)
FEATURES & BENEFITS
AVAILABLE OPTIONS
MODELS SIZE LOW LOSS HEADER KIT
1 Boiler 30-150 DN50 (2”BSP)
2 Boiler 60-300 DN65
3 Boiler 90-450 DN80
