28
EVOMOD BASIC OPERATING INSTRUCTIONS
continued...........
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
SETTING FLOW TEMPERATURE
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
State of Inputs
Rotate the KNOB clockwise until a screen similar to the following
is displayed
Set Flow Temp’
80°C
Press SELECT and a screen similar to the following will be displayed
Press + and - to change to the required setting and then press
ENTER to store
Rotate the KNOB anti-clockwise until Normal Operation is
highlighted again and press SELECT to return to normal operation
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Note that Off Mode will disable the Boiler
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
Ideal 750kW
Set Flow Temp’
Set Off/On Mode
State of Inputs
State of Outputs
Rotate the KNOB clockwise until a screen similar to the
following is displayed
Set Off/On
Off Mode
On Mode
Minimum
Maximum
Press SELECT and a screen similar to the following will be displayed
SETTING OFF/ON MODE
Press + and - to change to the required setting and then press ENTER
to store
Rotate the KNOB anti-clockwise until Normal Operation is highlighted
again and press SELECT to return to normal operation
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Ideal 750kW
Set Off/On
State of Inputs
State of Outputs
Fault History
Rotate KNOB clockwise until a screen similar to following is displayed
Ideal 750kW
Main Menu
Boiler Inputs
Module 1 Inputs
Press - for more
Press SELECT and a screen similar to the following will be displayed
Rotate the KNOB until the Inputs you would like to view are high-
lighted and then press ENTER
The state of the inputs will vary as the boiler operates
For the Boiler Inputs a screen similar to the following will be
displayed
VIEWING THE STATE OF THE BOILER INPUTS
For the Module Inputs a screen similar to the following will be
displayed
Module 1 Inputs
e-Bus Off
Flow Temp 80°C
Return Temp 60°C
Press - for more
Press SELECT to return to the sub-menu, rotate the KNOB anti-clock-
wise until Main Menu is highlighted and press SELECT. Rotate the
Knob anti-clockwise until Normal Operation is highlighted and press
SELECT to return to normal operation.
Boiler Inputs
Header Temp' 80°C
Switched Live On
0-10V Input 0V
External Interlock On
INSTALLATION
26
- Installation & Servicing
