EVOMOD BASIC OPERATING INSTRUCTIONS CONT'D
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
VIEWING THE STATE OF THE BOILER OUTPUTS
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Ideal 750kW
State of Inputs
State of Outputs
Fault History
Show Hours Run
Rotate KNOB clockwise until a screen similar to the following is displayed
Ideal 750kW
Main Menu
Boiler Outputs
Module 1 Outputs
Press - for more
Press SELECT and a screen similar to the following will be displayed
Rotate the KNOB until the Outputs you would like to view are
highlighted and then press ENTER
The state of the outputs will vary as the boiler operates
For the Boiler Outputs a screen similar to the following will be
displayed
Boiler Outputs
Header Pump On
Burner On Relay On
Fault Relay On
For the Module Outputs a screen similar to the following will be
displayed
Module 1 Outputs
Fan 3000rpm
Gas Valve On
Press SELECT to return to the sub-menu, rotate the KNOB
anti-clockwise until Main Menu is highlighted and press
SELECT. Rotate the Knob anti-clockwise until Normal
Operation is highlighted and press SELECT to return to
normal operation.
VIEWING THE FAULT HISTORY OF THE BOILER
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
Rotate KNOB clockwise until a screen similar to the following is displayed
Ideal 750kW
State of Outputs
Fault History
Show Hours Run
Normal Operation
Press SELECT and a screen similar to the following will be displayed
Fault History: Max 10
Fault 1 [Latest]
Ignition Lockout [16]
23 days ago
Press - for more
The Fault History will vary depending on the operation of the boiler
Press SELECT to exit this option
Rotate the KNOB anti-clockwise until Normal Operation is
highlighted again and press SELECT to return to normal operation
VIEWING THE BOILER HOURS RUN
Press SELECT and a screen similar to the following will be displayed
The kW output number in the 1st line will vary depending on the
maximum output of the boiler
Ideal 750kW
Normal Operation
Set Flow Temp’
Set Off/On
Rotate KNOB clockwise until a screen similar to following is displayed
Ideal 750kW
Fault History
Show Hours Run
Normal Operation
Press SELECT and a screen similar to the following will be displayed
Show Hours Run
Flame On Mod 1 20 h
Flame On Mod 2 20 h
Flame On Mod 3 20 h
Flame On Mod 4 20 h
The times will vary depending on the operation of the boiler
Press SELECT to exit this option
Rotate the KNOB anti-clockwise until Normal Operation is
highlighted again and press SELECT to return to normal
operation
INSTALLATION
27
- Installation & Servicing
