94 iDirect Satellite Router Installation and Commissioning Guide
iDX Release 3.3
Front-Panel LEDs
16.3 Front-Panel LEDs
Each Satellite Router features a number of front-panel LEDs that indicate acquisition and
network status. The installer or site operator can determine the state of the Satellite Router
by observing the LEDs and referring to the tables presented in this section.
16.3.1 Evolution e8350
Ta b l e 7 contains LED definitions for the Evolution e8350 Satellite Routers:
Table 7. iDirect Evolution e8350 LED Definitions
Label Color Definition
POWER Off No power or low power input
Green Valid power input detected
STATUS Off Power OFF, or executing DRAM test
Flashing Green DRAM test failed
Green Normal operation
Red Fault: software, hardware, or configuration
NE
T Off Satellite Router off or in sleep mode if TX is yellow
Ye
llow Demodulator not locked to the downstream
carrier
Flashing Yellow Demodulator locked. NCR not lo
cked.
Flashing Green (2 sec) Demodulator locked. NCR lock
ed.
Flashing Green (1 sec) Network acquisition and authentication in progress
Green The Satellite Router is in the network
TX Off Transmitter off. If STA
TUS is green, transmitter configured off.
Yellow Transmitter enabled and muted
Green Transmitter enabled and not muted
RX Off Receiver off or not configured
Yellow Demodulator not locked to the downstream carrier
Flashing Yellow Demodulator locked. NCR not lo
cked.
Green Demodulator locked. NCR lock
ed.
CRYPTO Off FIPS mode not enabled
Green FIPS mode enabled
FAN Off No fan alarm
Red Fan alarm detected
TEMP Off Normal operating temperature
Yellow Operating temperature near o
v
er-temperature threshold
Red Operating temperature exceeds over-tempera
ture threshold
