6. KIOSK V LED and Sound State Indicators
The KIOSK V uses the following LEDs and sounds to indicate various statuses, including power
management, Bluetooth, transactions, and security.
Device State
LED1
LED2
LED3
LED4
Beeper
1
Device FW, certificates, or keys
self-test failed.
○
off
○
off
○
off
●
blink
Beeps
Device Tampered
○
off
○
off
○
off
●
blink
Beeps
Device Deactivated
○
off
○
off
○
off
●
blink
Beeps
Device Activated
2
○
off
○
off
○
off
●
on
Off
Device Key Missing
3
●
blink
●
blink
●
blink
●
blink
Off
Ready for Transaction
●
blink
○
off
○
off
○
off
Off
Connecting to Bluetooth
○
off
○
off
○
off
●
blink
Off
Bluetooth Connected
○
off
○
off
○
off
●
on
Beeps
Once
Bluetooth Connection Failed
○
off
○
off
○
off
●
on
Beeps
Twice
Bluetooth Transmitting Data
○
off
○
off
○
off
●
on
Off
Transaction Started
4
●
on
○
off
○
off
○
off
Off
Transaction Successful
5
●
on
●
on
●
on
●
on
Beeps
Once
1
Note that “beeps” indicates constant beeping unless the description includes a specific number of beeps (such
as “twice”).
2
The device has loaded certificates successfully and is activated.
3
The device only has LCL-KEK; the required key is not injected.
4
The transaction has started and the device is waiting to read a card.
5
LEDs remain on for 1000ms.
