3. Kiosk V Specifications
Hardware
MTBF
500,000 hours based on Telcordia Technologies SR-332 modeled at 40° C.
Transmitter Frequency
13.56 MHz +/- 0.01%
Transmitter
Modulation
ISO 14443-2 Type A
Rise/Fall Time: 2-3 µsec. Rise, < 1 µsec fall ISO 14443-2 Type B
Rise/Fall Time: < 2 µsec. each; 8% - 14% ASK ISO 18092
ISO 21481 (PCD & NFC)
Receiver Subcarrier
Frequency
847.5 KHz
Receiver Subcarrier
Data
ISO 14443-2 Type A: Modified Manchester ISO 14443-2 Type B: NRZ-L, BPSK
ISO 18092
ISO 21481 (PCD & NFC)
Typical Read Range
0-4 cm (0 to 1.5 inches)
Physical
Length
75 mm (2.95 inches)
Width
60 mm (2.36 inches)
Depth
9.6 mm (0.38 inches)
Environmental
Operating
Temperature
-30° C to 70° C (-22° F to 158° F), max change of 10° C per hour
Storage Temperature
-40° C to 85° C (-40° F to 185° F) [non-condensing]
Operating Humidity
Up to 90% non-condensing, maximum 95%
Storage Humidity
Up to 90% non-condensing, duration 3 months
Transit Humidity
Up to 95% non-condensing, duration 1 week
Operating Environment
Water resistant for indoor and outdoor use
IK Rating
IK 08
IP Rating
IP 65
Electrical
Reader Input Voltage
+5V (USB port-powered)
Working Current Rated
power
Maximum field
strength Battery (for
real-time clock)
400mA in Auto Polling mode
<1000Mw
2.6 dBuA/m at 3m
CR2032 20.5mm x 4.5mm, 220 mAh ("coin" battery), lifetime 5 years
