0x32 – MSR Reading
Buffered Mode Enabled
0x33 Auto MSR Buffered
Mode Enabled
DTEnableSen
dID
1B
DT Enable
Send
‘0’(‘0’,’1’,’3’)
Data Editing Control
0x30 – Disable Data Edit.
0x31 – Data Edit Match
mode.
0x33 – Data Edit Unmatch
mode
i
d
DecodingMeth
odID
1D
Decoding
Direction
‘1’ (‘0’~’3’)
Reading Direction
0x30 – Raw Data Decoding
in Both Directions.
0x31 – Decode in Both
directions.
0x32 – Moving Stripe Along
Head in Direction of
Encoding.
0x33 – Moving Stripe Along
Head Against Direction of
Encoding.
ReviewID
1F
Review All
Settings
None
TerminatorID
21
Terminator
0x0D (any)
CR for RS232, Enter for KB
i
FmVerID
22
Firmware
Version
None
USBHIDFmtI
D
23
USB HID Fmt
(HID rdr only)
‘0’ (‘0’~’1’,
‘8’)
‘0’ ID TECH Format; ‘1’
Mag-Tek Format; ‘8’
HIDKB format
u
r
ForeignKBID
24
Foreign KB
'0' ('0' ~0x3A)
Foreign Keyboard
k
CustSetID
30
Custom
Customer
Settings
00(00-07)
.0 POS-X: Level 3 Non-CC
send same as Level1
.1 Level3: No empty pkt
when not enough sampling
bits
.2 Enhanced Secured Output
will have SN after hash
Track1PrefixI
D
34
Track 1 Prefix
0 (any string)
No prefix for track 1, 6 char
max
i
Track2PrefixI
D
35
Track 2 Prefix
0 (any string)
No prefix for track 2, 6 char
max
i
Track3PrefixI
D
36
Track 3 Prefix
0 (any string)
No prefix for track 3, 6 char
max
