SecureMag User Manual
Track1SuffixI
D
37
Track 1 Suffix
0 (any string)
No suffix for track 1, 6 char
max
i
Track2SuffixI
D
38
Track 2 Suffix
0 (any string)
No suffix for track 2, 6 char
max
i
Track3SuffixI
D
39
Track 3 Suffix
0 (any string)
No suffix for track 3, 6 char
max
i
PinKeyID
3E
0x00,0x5A
0x00-Data Key; 0x5A–
PinKey Can only set at
secure level 1;
r
BaudID
41
Baud Rate
‘5’ (‘2’~’9’)
9600 bps, ‘2’ is 1200, ‘7’ is
38,400 bps; ‘9’ is 115.2 kbps
s
DataID
42
Data Bit
‘0’ (‘0’~’1’)
‘0’-8 Bits required in secure
mode’1’-7 bits
s
ParityID
43
Data Parity
‘0’ (‘0’~’4’)
‘0’-None ’1’- Even, ‘2’-Odd,
‘3’-Mark or ‘4’-Space
s
HandID
44
Hand Shake
‘0’ (‘0’~’1’)
Software (Xon/Xoff) hand
shake
s
StopID
45
Stop Bit
‘0’ (‘0’~’1’)
‘0’-1 stop Bit; ‘1’-2 stop bits
s
XOnID
47
XOn Character
DC1
0x11 as XOn
s
XOffID
48
XOff Character
DC3
0x13 as XOff
s
PrePANID
49
PAN to not
mask
4 (0-6)
# leading PAN digits to
display
e
PostPANID
4A
PAN to not
mask
4 (0-4)
# of trailing PAN digits to
display
e
MaskCharID
4B
mask the PAN
with this
character
‘*’ 20-7E
any printable character
e
CrypTypeID
4C
encryption type
‘0’ (‘0’-‘2’)
‘0’ no encryption ‘1’ 3DES
‘2’ AES
r
e
OutputModeI
D
4D
Std, OPOS or
JPOS
'0' ('0' ~ '2')
Reader does
not save in
non-volatile
memory.
‘0’-Standard mode; ‘1’
OPOS; ‘2’-JPOS
Always returns to ‘0’ on
power-on.
SerialNumberI
D
4E
device serial #
any 8-10 bytes
8-10 digit serial number;
Can be set only once
r
DispExpDateI
D,
50
mask or display
expiration date
'0''0'-'1'
‘0’ mask expiration date; ‘1’
display expiration date
e
SessionID
54
8 byte hex not
stored in
EEPROM
None
always init to all ‘FF’
e
Mod10ID
55
include mod10
check digit
'0' ('0'-'2')
‘0’ don’t include mod10, ‘1’
display mod10, ‘2’ display
wrong mod10
e
