Basic settingp.36
the instructions on the Time Schedule Setup in the [F4 SETUP MENU]. If you wish to giv
e the cardholder unlimited access time, enter the default Time Schedule code '00' for th
e value.
●
RD
Refers to the Reader Assignment code for the cardholder. Entering the code ‘0’ and '3' a
ssigns both readers (Built-in Reader and Exit Reader) to grant access to the cardholder t
hat is being registered, code ‘1’ only assigns Reader*1 (Built-in Reader) and code ‘2’ assi
gns Reader*2 (Exit Reader). If you enter ‘1’ in the RD field(Only Reader*1 assigned) and
try to exit through Reader*2 (Exit Reader) then the LX007 generates an error message
(“Access Door Error”) on the LCD display.
●
C
Refers to the ID code. Code ‘0’ is default and codes ‘1’ and ‘2’ are codes are used for the
TWO MEN MODE. Code ‘3’ is used for the ARM/DISARM function and code ‘4’ is assigne
d for lost cards.
●
MA
Refers to the Operating Mode that the new cardholder will use on Reader*1 (i.e. the bu
ilt-in reader). If you enter ‘1’ for MA, for example, this card holder will be able to gain ac
cess using his or her ID only.
○
‘0’ – Depend on System Operating Mode ([F1 SETUP MENU] > [READER*1 MODE])
○
‘1’ – ID Only Mode
○
‘2’ – ID + Fingerprint (Password)
○
‘3’ – ID + Password + Fingerprint
●
MB
Refers to the Operating Mode that the new cardholder will use on Reader*2 (Exit Reade
r).
○
‘0’ – Depend on System Operating Mode ([F1 SETUP MENU] > [READER*2 MODE])
○
‘1’ – ID Only Mode
○
‘2’ – ID + Password Mode
You cannot apply the ID + Password Mode if Reader#2 does not have a keypad or
does not use password verification.
●
LV
Refers to the Output Operating Level for the new cardholder. Output operating time ca
n be set for each user. To define an output operating time for each level, refer to the ins
tructions on Output Setting in [F6 SETUP MENU].
○
‘0’ or ‘1’ – Level *1
○
‘2’ – Level *2
○
‘3’ – Level *3
To Next Page
