p.85A. THE RELATION BETWEEN INPUT AND OUTPUT (DEFAULT)
E OUT
[10] OUTPUT T
IME SCHEDUL
E
00 00 00 00 00
INPUT Exit Button (EX
)
Door Contact
Sensor (DC)
Aux Input #1 (I
1)
Aux Input #2 (I
2)
Tamper Switch
(TP)
[11] INPUT TI
ME SCHEDULE
00 00 00 00 00
[12] CUT OFF
CHECK
00 00 00 00 00
[13] INPUT TY
PE
00 00 00 00 00
* Index No. [1] - [9]
The values indicate the operating time of each output for the input signal.99 denotes
“forever”.
* Index No. [10]
The values indicate the time schedule code (index) applied to each output.
* Index No. [11]
The values indicate the time schedule code (index) applied to each input.
* Index No. [12]
The values indicate whether or not to use the cut off check feature for each input. (0
– NOT USE, 1 – USE)
* Index No. [13]
The values indicate whether the input type is NO(Normally Open) or NC(Normally Clos
ed). (0 – NO, 1 – NC)
Table 13-2 Default Output Settings for Input Circumstance
OUTPUT
INPUT
Door Relay
(DR)
Alarm Relay
(AR)
TTL#1
(T1)
TTL#2
(T2)
Buzzer
(BZ)
[1] Reader#1 I
D OK LV1
03 00 00 00 00
[2] Reader#1 I
D OK LV2
05 00 00 00 00
[3] Reader#1 I
D OK LV3
05 00 00 00 00
[4] Reader#1 I 0500 00 00 00
