4 - HANDLING AND INSTALLATION MASTER 880MP E-volution
GB
4 - Pag. 15 / 17
4.4.6 Feeder fastening
CAUTION:
failure to fix the bar
feeder to the ground or
bad bar feeder fixing to
the ground can be the
main cause of bar feeder
bad operation and
resulting damaging.
• Drill the floor and fix the backing
plates with expansion plugs. Drill
the floor and fix the backing plates with the expansion plugs. Use the highest possible
number of plugs in order to guarantee good fixing.
• Fix the feeder to the plates through the tie-rods A and lock with nuts B.
• Perform another levelling and alignment check.
• Remove all the equipment used for levelling and alignment and restore initial feeder
conditions.
