► Connect all required supply lines, GND connections and the shield connection�
6.2 Connection technology
Observe all notes on connection technology�
► Note the device label�
► Use M12 connectors with gold-plated contacts�
► The M12 connection parts in the device comply with the ingress resistance
requirements of the standard EN 61076-2-101� To adhere to the protection
rating, only cables certified to this standard must be used� The system architect
undertakes to ensure the ingress resistance of cables they have cut to length�
► Carry out the fitting according to the indications of the cable manufacturer� The
permitted maximum is 10 Nm�
► During installation, place the M12 connectors vertically so that the coupling nut
will not damage the thread�
► Equip unused sockets with protective caps (included)� Tightening torque: 0�8
±0�1
Nm
► Use 81-pole connectors with individually sealed cores to ensure protection
rating IP 67�
Only connect the 81-pole connectors when the supply voltage is
disconnected� "Hot plugging" is not permitted�
The ingress resistance of cables that users have cut to length must be
guaranteed�
► Use twisted-pair cables for the CAN connection�
► For the Ethernet connection, use at least a category 5 cable (Cat 5)�
The RS-232 interface serves only as a service interface (e�g� for firmware
updates)�
► Provide all outgoing cables with a strain relief 200 mm behind the cable entry�
