21
UK
6.9 Analogue outputs
supply
controller
VBB
30
nn
VBB
15
nn
VBB
0
nn
VBB
1
nn
VBB
2
nn
VBB
3
nn
VBB
4
nn
VBB
5
nn
GND
SYS
nn
GND
1...4
nn
load
A (0...10 V)
A (0...10 V)
GND
OVA
Con. B
52
GND
OVA
Con. A
33
32
51
Con. A
Con. B
Shield
load
Connection of the analogue outputs (A), example CR721S
The controller can be connected to the following loads:
• resistive loads
The connected load must not exceed the maximum permissible values of the
respective output (→ 8 Technical data)�
► Connect the GND of the load to GND
OVA
�
Do not connect the GND of the load to other GND connections or to the
common GND star point�
Deviating connections are not permitted�
