INSTALLATION
❖ Connecting your IGLOO
Before starting, choose a suitable position for your IGLOO, observing the
ventilation requirements set out on page 2.
Warning
Before you connect or disconnect your IGLOO to/from any other equipment,
make sure you disconnect all the equipment from the mains supply.
Connecting to a TV
If you have a TV with only a composite (CVBS) video input, use the supplied AV
phono leads (yellow, white, red cable) to connect your IGLOO (see page 8). Match
the colours of the connectors on your IGLOO and leads.
If your TV has component video (Y Pb Pr) inputs, you can connect your IGLOO
to your TV using a suitable lead (not supplied) as shown on page 8. This will give
a better quality picture on your TV for standard definition only. You also need to
connect the audio leads.
If your HDTV has HDMI inputs, you can connect your IGLOO to your TV using
a standard HDMI cable (not supplied) as shown on page 8. This will give you the
best picture and audio quality on your TV.
For the HDMI connection, you do not need to connect any additional audio
leads. (Limited to stereo audio only.)
Note
To view high-definition picture on your HDTV, you must connect your IGLOO
to your HDTV using a standard HDMI cable (not supplied).
Optional audio connections
You can obtain improved quality sound with optional audio connections.
You can connect to a home cinema or stereo audio equipment as shown on
page 8.
Note
If you connect to your TV, or other equipment via the COMPONENT VIDEO
OUT, VIDEO OUT connectors, you must also use an audio connection, in order
to hear sound.
