3.6 Accessories for the Chassis
Part. No.
Description
474-2RMK 19"-Rackmount Ears for Draco vario 2-Slot chassis
474-2NRMK 19"-Rackmount Ears for Draco vario 2-slot chassis w/ built-in PSU
474-4RMK 19"-Rackmount Ears for Draco vario 4-Slot chassis
474-6RMK 19"-Rackmount Ears for Draco vario 6-slot chassis
474-VPLATE Mounting plate for 2-/4-/6-slot chassis
474-VSNAP
Mounting plate w/ DIN Rail Snap On for 2-slot chassis
474-BRACKET Wall-/Tablemount L-Brackets for all 2-/4-/6-Slot chassis
474-PSU2 Spare ext. PSU for 2-slot chassis
474-PSU2BPF Spare ext. PSU for 474-BODY2-BPF, lockable connector
474-PSU4 Spare ext. PSU for 474-BODY2N and 474-BODY4/4R
474-PSU6 Spare ext. PSU for 474-BODY6R-R1
474-PSU21 Spare PSU for 474-BODY21/4U, slide-in, hot-swap
474-BLND1 Blanking plate with IHSE Logo, 1-slot for Draco vario chassis
474-6FAN Optional fan for Draco vario 2-slot and 6-slot chassis with backplane
260-5G International power supply unit 100...240VAC/5VDC/3A
260-5M International power supply unit 100...240VAC/5VDC/5A
PC-TYP-E/C13-020 Power cord IEC Schuko 90° Type-E/C13 2.0 m lockable
PC-TYP-B/C13-020 Power cord IEC US Type-B/C13 2.0 m lockable
All external power supplies are
separately certified according to all relevant safety standards.
3.7 Accessories for the U-Switch Module
Part. No. Description Interface
247-U1 USB cable Type A-B, 1.8 m USB/USB-HID
247-U2 USB cable Type A-B, 3.0 m USB/USB-HID
436-USB20 USB extension cable Type A-A, 3.0 m USB/USB-HID
476-CTRL4-GPIO Remote Control for Draco vario GPIO module with 4 push
buttons/LEDs (cable length approx. 3.0 m)
GPIO
