Ihse Draco U-Switch User Manual

Draco U-Switch Technical Data
59
12.3 Power Supply Voltage, Current Draw and Power Consumption
NOTICE
Overheating of the power supply units
In case of having redundant power supply units, the maximum current must not exceed the value of one
of the two power supply units due to the heat dissipation.
12.3.1 Power Supply Voltage of the Chassis (AC)
Product type Maximum current draw Maximum voltage AC Frequency
474-BODY2N 700 mA 100 V to 240 V 50/60 Hz
474-BODY2BPF 700 mA 100 V to 240 V 50/60 Hz
474-BODY6R-R1 1,500 mA 90 V to 264 V 47-63 Hz
474-BODY6BP 1,300 mA 100 V to 240 V 50/60 Hz
474-BODY6BPF 1,300 mA 100 V to 240 V 50/60 Hz
474-BODY21/4U 4,000 mA 2x 100 V to 240 V 50/60 Hz
12.3.2 Power Supply Voltage of the Chassis (DC)
Product type Maximum current draw Maximum voltage DC
474-BODY2 3,000 mA 5 V
474-BODY2R 3,000 mA 5 V
474-BODY2N 5,000 mA 5 V
474-BODY2BPF 5,000 mA 5 V
474-BODY4 5,000 mA 5 V
474-BODY4R 5,000 mA 5 V
474-BODY6R-R1 12,000 mA 5 V
12.3.3 Power Supply Voltage of the U-Switch Module and Add-on Modules
NOTICE
Exceeding the maximum permissible current draw
In addition to the current draw of the U-Switch module and add-on modules, there is also the current draw
of the connected peripherals.
 Note the maximum current draw of the housing (see from chapter 12.3, page 59).
Product type
Maximum current draw
Maximum power consumption
B476-4U4T 1,710 mA 8 W
R474-BGX 10 mA 0 W
