12.4 Environmental Conditions and Emissions
Parameter
Value
Operating temperature 5 to 45 °C (41 to 113 °F)
Storage temperature -25 to 60 °C (-13 to 140 °F)
Relative humidity Max. 80% non-condensing
Operating altitude Max. 2,500 m (7,500 ft)
Sound pressure level
(SPL)
Max. 21 dBA per fan (474-6FAN and 474-MODFAN)
Heat dissipation Corresponds to power consumption in Watt (W)
12.5 Dimensions
12.5.1 Dimensions of the Chassis
CPU Unit / CON Unit Dimension Dimension of the shipping box
474-BODY2 /
474-BODY2R
145 x 147 x 41 mm (5.7" x 5.8" x 1.7") 267 x 216 x64 mm (10.5" x 8.5" x 2.5")
474-BODY2N 221 x 147 x 41 mm (8.7" x 5.8" x 1.7") 267 x 216 x64 mm (10.5" x 8.5" x 2.5")
474-BODY4 /
474-BODY4R
293 x 147 x 41 mm
(11.5" x 5.8" x 1.7")
550 x 365 x 115 mm
(21.7" x 14.4" x 4.5")
474-BODY6R-R1
442 x 147 x 41 mm
(17.4" x 5.8" x 1.7")
760 x 365 x 115 mm
(29.9" x 14.4" x 4.5")
474-BODY6BP /
474-BODY6BPF
442 x 250 x 44 mm
(17.4" x 9.8" x 1.7")
550 x 372 x 155 mm
(21.7" x 14.6" x 6.1")
474-BODY21/4U
482 x 462 x 176 mm
(19.0" x 18.2" x 6.9")
645 x 574 x 368 mm
(25.4" x 22.6" x 14.5")
12.5.2 Dimension of the U-Switch Module and Add-on Modules
Dimension
Dimension of the shipping box
B476-4U4T 120 x 20 x 145 mm
(4.7" x 0.8" x 5.7")
250 x 191 x 38 mm
(9.84" 7.52x" 1.5x")
R474-BGX 120 x 20 x 145 mm
(4.7" x 0.8" x 5.7")
250 x 191 x 38 mm
(9.84" 7.52x" 1.5x")
