Ihse Draco U-Switch User Manual

Draco U-Switch Configuration
41
Entering or Changing a Parameter in the Configuration File
To enter or change a parameter of the U-Switch, proceed as follows:
1. Connect the U-Switch to any source using a Mini-USB cable.
The U-Switch opens a flash drive containing the Config.txt file.
2. Open the Config.txt file in a text editor.
3. Ensure that #CFG is written in the first line of the file.
4. Add a line break directly behind #CFG.
5. Add the desired parameter in capitals in the line below #CFG.
6. Save the Config.txt file.
7. Manually power off the U-Switch.
8. Power on the U-Switch.
The U-Switch starts automatically with the respective setting for the USB 2.0 ports.
Fig. 37 Example - Config.txt with parameter to activate the routing of USB ports 1 and 4
