IK Multimedia UNO Synth User Manual

UNO Synth
9 – Specications
37
Connections
• AudioOut:Mini-jack3.5mmstereo(monosummed)
• AudioIn:Mini-jack3.5mmstereo(monosummed)
• 2xMIDI2.5mmmini-jacktoDINcables(IN/OUT)
• 1MicroUSB*
Power
• 4xAABatteries
• MicroUSBconnector
Dimensions
• Size:25.6cm/10.1”x15cm/8.9”x4.9cm/1.93”
• Weight:400g/14.1oz(batteriesexcluded)
*USBpowerhasinherentgroundnoise,sowhenconnectingtheUNOSynthdirectlytoyourcomputerviaUSB,
youmayhearmorenoiseandinterferencethanwhenthesynthisconnectedtoaUSBwallchargerorrunning
viabatteries.Withthedirectcomputerconnection,youcanreducetheUSBgroundnoiseandotherinterference
byeitherusingaUSBisolatororacustomTRScableintoabalancedinputonyourpreamporaudiointerface
wherethegroundisnotconnectedbalancedattheinputside.
UNO Synth Output
1/8” TRS
to TRS 1/4”
Balanced Input
Tip Ring Sleeve TipRingSleeve
1 2
3
Tip
Tip
Ring
Ring
Sleeve
Sleeve
UNO Synth Output
1/8” TRS
to XLR
Balanced Input
Tip Ring Sleeve
Tip
Ring
Sleeve

IK Multimedia UNO Synth Specifications

General

Type	Analog
Polyphony	Monophonic
LFO	1 LFO
Effects	Delay
Sequencer	16-step sequencer
Connectivity	MIDI In/Out, USB
Power	USB power or 4x AA batteries
Dimensions	25.6 x 15 x 4.9 cm
Weight	400 g
Oscillators	2 x VCO with continuously variable waveshape: triangle, sawtooth, pulse with PWM
Filter	2-pole resonant multimode filter (LP/HP/BP)
Keyboard	27 capacitive touch keys
