PROGRAMS
Under programs, 10 user-defined temperature-time pro-
files can be created� A program can consist of up to 10
segments�
Once a program has been selected, the following op-
tions are available:
1. Start:
Starts the program upon request of loop mode�
1) Infinite loop: Upon completion of the last segment,
the program continues with the first segment until the
user ends the program by stopping a device function�
2) Loop Count: Indicates the total number of loop cy-
cles until program end�
Note: At the end of the program all device functions
are switched off
2.Edit:
Edit/change program�
1) Seg No.: Segment number
2) Ctrl. Sensor (int/ext): Determines whether control is
through the internal (int) or external (ext) temperature
sensor
3) Temp.: Target temperature�
4) Ctrl.Mode (Time / +/- x.x K / Ramp): In "Ctrl�Mode
Time" the target values and settings of the segment are
valid for the duration indicated in the column "Time
hh:mm"�
Afterwards, the next program segment is automatically
executed�
In "Ctrl�Mode +/- x�xx K", the hysteresis (tolerance) of
the actual temperature to the target temperature is set
(e�g� +/- 0�1 K)� The target values and settings of the
segment are valid until the actual temperature reaches
the target temperature +/- hysteresis for the first time�
Afterwards, the next program segment is automatically
executed�
GRAPH
In this menu, you can set the options for the time-tem-
perature diagram�
1. Automatic:
The scaling of the temperature axis (Y-axis) is automati-
cally determined, depending on the target temperature
and the actual internal and external temperature
The time axis (X-axis) is permanently scaled to 30 minutes�
2. Manual:
1) Axis Assignment:
The temperature values to be displayed can be selected�
2) Axis scaling:
Scaling of the time (X) and temperature axis (Y) can be
selected or set�
DISPLAY
1. Main Screen:
In the “Main Screen“ menu option, you can specify
what information will be displayed on the screen�
2. Device Number:
In the “Device number“ menu option, you are allowed
to edit the device number from 0 to 99 that will be
shown on the main screen�
When using multiple units, it may be helpful to identify
WiCo and station
Note: Labeling device number to the station
MODE
1. Operating Mode A:
After power-on/power failure no automatic restart of
functions�
2. Operating Mode B:
After power-on/power failure automatic restart of func-
tions, depending on previous settings�
3. Operating mode C:
Set values (set in A or B) cannot be changed�
After power-on/power failure automatic restart of func-
tions, depending on previous settings�
4. Operating mode D:
Confirmation request for set value changes, if functions
are active� After power-on/power failure no automatic
restart of functions�
TIMER
1. Set:
The user can set a target time (duration)�
When device functions are started normally, this time is
displayed on the working screen� The device functions
stop automatically once this time has expired� The run-
ning time is then displayed again on the display
Note: To deactivate the target time specification, set
the target time to 00:00�
2. Display:
Activate the timer display on the main display (working
screen)�
PUMP
Limits:
In “Limits“ option, the user is allowed to set the maxi-
mum and minimum speed to the pump, and also the
maximum pressure�
