NOTE: The function related to pressing the key briefly is performed by pressing the key which will activate
the function assigned to it. On the other hand, to perform the function carried out when the key is held down
longer, press the key until the relative function is started. The buzzer will beep shortly to signal that the
function has been activated.
NOTE: Warm-up: When the equipment has not been used for a prolonged period (more than 3 months) or
when turned on for the first time, it is advisable to perform a series of emissions with short times (0.01-0.02
sec.) and then, progressively, some pictures with 0.1 sec. intervals to better stabilise the operation of the x-
ray tube before using it.
4.3. CHECKING THE PARAMETERS
Before actually taking an exposure, make sure that the exposure parameters for the examination in progress are
correctly set:
- Checking the selected patient size.
- “SMALL” symbol selected: indicates that the x-ray unit is set for patients with small builds.
- “LARGE” symbol selected: indicates that the x-ray unit is set for patients with average-large builds.
Average/large build (LARGE) selected
Small build (SMALL) selected
NOTE: After the change has been made, the preset exposure times will automatically be modified.
- Checking the selected type of intraoral exam.
Upper canines/bicuspids or rear
“bite-wing” exam
Lower canines/bicuspids exam
Upper incisors
or front “bitewing” exam
