15 Image Vault
®
PRO Command
PTZ/Alarm Outputs
Serial POS Data Hub Connection
If you have three or more POS data sources you will need one or up to two IVQuad hubs. Each IVQuad hub device o ers four data input
ports. With two serial ports on the DVR, this means up to 8 serial data sources may be connected to one DVR. IVQuad data hubs are
sold separately.
Multi-Device Print Server Serial Data Connection
Though not as common, Image Vault also supports multi-device serial print server applications.
The wiring is the same as the direct connection, but through software your DVR can di erentiate
source channels.
