IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
125General technical Specs
6 Technical Specs
6.1 General technical Specs
Parameter
Value
Remarks
Housing type
alu profile
plastic portable housing
CS
CL
Ingress protection
IP20
Terminal connection
Terminal connection
DI, DO, INC, DAC
1x DSUB-15
1x DSUB-15
1x DSUB-15
1x DSUB-15
8 digital inputs
8 digital outputs
4 counter inputs
4 analog outputs
Further terminal connection
RJ45
CF-Card Slot
2x DSUB-9
DSUB-9
DSUB-9
BNC
LEMO FGG.1B.302
LEMO FGG.0B.302
LEMO FGG.0B.306
Ethernet (100 MBit), PC/network
removable storage
two CAN FD nodes
external display (CS)
external GPS module
synchronization
supply CL
supply CS
REMOTE
Weight
ca. 2 kg
ca. 3.5 kg
CS
CL
Dimensions (WxHxD) in mm
95 x 111 x 185
270 x 85 x 300
CS
CL
Power supply
Value
Remarks
Power supply
10 V to 32 V DC
Isolation of supply input
not-isolated
isolated
CS
CL
AC/DC adaptor
110 V to 230 V AC
external adaptor included in delivery
Auto start upon power up
configurable
automatic start of measurement
